Window sizes

  18MM Series
(Approx Weight Kgs)
25MM Series
(Approx Weight Kgs)
25MM Taper
(Approx Weight Kgs)
30MM Series
(Approx Weight Kgs)
2 Track Window Medium Heavy
  -  4' x 4' 6/200 8/300 8/500 15/600 13/300
  -  5' x 4' 7/400 10/050 10/750 19/350 13/450

3 Track Window
  -  5' x 4' 10/350 14/000 15/500 27/300 17/500
  -  6' x 4' 10/300 14/150 16/000 26/200 17/950
  -  6' x 5' 12/200 16/350 19/000 29/900 20/650
  -  6' x 6' 12/600 17/000 18/900 32/450 22/550
  -  8' x 4' 12/000 16/000 17/800 30/250 20/300
  -  8' x 5' 14/300 19/200 20/300 34/100 21/250
  -  8' x 6' 14/300 19/200 22/000 36/600 25/200
  -  10' x 4' 16/100 21/500 22/500 35/600 24/850
  -  10' x 5' 16/200 21/100 23/750 39/500 26/900
  -  10' x 6' 17/500 23/400 25/650 42/200 28/750

4 Track Window
  -  6 ' x 4' 14/000 15/750 19/300 32/050 25/650
  -  6' x 5' 18/000 20/750 22/000 36/950 29/100
  -  8' x 4' 17/500 19/650 21/900 36/450 26/200
  -  8' x 5' 19/600 21/850 24/900 41/800 30/950
  -  8' x 6' 21/300 23/600 26/850 45/450 35/800
  -  10 ' x 4' 20/450 22/850 25/700 42/950 33/100
  -  10 ' x 5' 22/700 21/100 26/100 47/900 31/000
  -  10' x 6' 22/750 26/600 30/750 51/650 40/250
  -  12' x 4' 22/250 24/600 27/500 46/300 35/700
  -  12' x 6' 25/350 29/200 32/750 55/000 42/850

5 Track Window
  -  12' x 4' 24/250 26/600 29/300 - -
  -  12' x 6' 29/300 33/000 37/600 - -

Aluminium Sections Surface Chart (Area in sq. inch)

Aluminium Sections 18 mm 25 mm 25mm Taper 30 mm
5 Track Bottom 32 - - -
5 Track Top 28 - - -
4 Track Hollow 27 32.00 - -
4 Track Bottom 24.50 26.50 31 35
4 Track Top 21 22.50 30 30
3 Track Hollow 21 23 - -
3 Track Bottom 20.50 21 28 23
3 Track Top 18 19 23 20
2 Track Hollow 16 16 - -
2 Track Bottom 14 15.50 18 17.50
2 Track Top 12 13.50 16 15.50
Handle 6.5 8 9 8.50
Interlock 8 9.50 12 12
Top Bottom 6 12 14.50 12
Bearing Bottom 9 12 14.50 12
Middle 8 10 13 -
Z Frame 8 R Frame 9 R Frame Big 11
Z Shutter 8.50 R Shutter 10 21/2 x 11/2 D.P 9
Z Mulian 9.50 R Mulian 11 21/2 x 11/2 S.P 8.5
Z Clip 5 R Clip 6.5 - -

Telephone Interlock 10 Tele. Frame 9 1" Angle 4
Door Top 8 2 x 1 R/T 6 2" Angle 8
Door Bottom 14 3 x 1 R/T 8 3/4" Angle 3
Door Middle 8 4 x 1 R/T 10 1/2" Angle 2
Door Verticle 8 5 x 1 R/T 12 1/2 U 3
Glazing Clip 3 6 x 1 R/T 14 1 x 1/2 U 4
Glazing Plate 4 2 1/2 x 1 R/T 7 1/2 x 3/4 U 3.5
Glazing Angle 7 2 1/2 x 1 1/2 R/T 8 3/4 U 4.5
Louvers Plate 4 3 1/4 x 1 1/2 R/T 9.5 5/8 U 3
Curtain Wall Big 14.50 4 x 1 1/2 R/T 11 Dhumal 2 T 10
Curtain Wall Small 11.50 1 x 1/2 R/T 3 Dhumal 3 T 20
Curtain Wall Clip 4 Sound Proof H/L 10 Dhumal H/L 12
Curtain Wall Cover 7 Sound Proof I/L 15 Dhumal Clip 5
Grill F 3.50 Sound Proof B/B 15 - -
